Deskripsi
Fitur:
Standards and Compliance:
SPLN D3.023:2021
Kominfo, TKDN, CE, ROHS
Frequency Bands:
4G LTE-TDD : 2300 MHz
4G LTE-FDD : 850/900/1800/2100 MHz
UMTS/HSPA : 900/2100 MHz
GSM/GPRS/EDGE : 900/1800 MHz
Data Rates (Maximum):
4G LTE-TDD : 150 Mbps (Download)/50 Mbps (Upload)
4G LTE-FDD : 130 Mbps (Download)/30 Mbps (Upload)
Electrical:
Supply Voltage : 5 – 24 Volt DC
Max Power Consumption (operation) : 4 VA
Max Power Consumption (standby) : 0.4 VA
Memory:
96 kB RAM & 3 MB Flash
Temperature:
Operating : -25 °C to 65 °C
Storage : -25 °C hingga 85 °C
Humidity : max 95% (non condensing)
Ingress Protection:
IP 52
Interface:
SMA Female antenna connector
RJ45 Port for serial RS 232 (data communication)
Power supply Connector DC plug 5.5 mm/2.1 mm female
Mini SIM (2FF) : 3V/1.8V
USB Port (internal)
Multi indicator LED
Features:
Services: 4G LTE/2G
Protocols : UDP, TCP, & MQTT
Support AT Command 3GPP (TS 27.007) and AT Command customization
Automatic call, call blocker
SMS services: PDU & Text
Auto delete SMS
Support firmware upgrade by USB connection or remote Firmware Over The Air (FOTA)
Compatible with various brands of kwh meters
Dimension:
Material : Polymer Polycarbonat
Dimension : 85 mm (L) x 70 mm (W) x 25 mm (D)
Weight: ± 70 gram
